Adapter Sleeve H3260 H3264 H3268 H3272 H3276 H3280 H3284 H3288 H3292 H3296 H32/500

Price:	1.0~6.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Tianjin, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: H3272 H3276 H3280 H3284 H32...

Production Capacity: 1000000 sets / week

Delivery Date: according to the quantity

Means of Transport: Ocean,Air

Packing: as per customer's requireme...

reasonable price and good quality

1.Product name: Adapter Sleeve H3260 H3264 H3268 H3272 H3276 H3280 H3284 H3288 H3292 H3296 H32/500

2.Type of Adapter Sleeve: H23 Series

3. Partial Specification of Adapter Sleeve:

Designation	Principal dimensions
	d1	d	d2	B1	B2	B'2
	mm
H3260	280	300	380	2340		53
H3264	300	320	400	258		56
H3268	320	340	440	288		72
H3272	340	360	460	299		75
H3276	360	380	490	310		77
H3280	380	400	520	328		82
H3284	400	420	540	352		90
H3288	410	440	560	361		90
H3292	430	460	580	382		95
H3296	450	480	620	397		95
H32/500	470	500	630	428		100

4.Package: according to the customer's requirements, general the packages is box.

5.Usage:

1)Adapter sleeve is used to fix the conic aperture self-aligning ball bearing (self-aligning ball bearing, self-aligning roller bearing) on the non-bearing shoulder bearing. It is simply structured and its working is reliable. Easy to replace the bearing.

2) Widely applied in the lines of textile, light industry, metallurgy, belt convey and transmission equipment, etc.

6.Features:

1) Adapter sleeves are the most commonly used components for locating bearings with a tapered bore onto a cylindrical seating as they can be used on smooth or stepped shafts.

2) They are easy to mount and require no additional location on the shaft.

3) When adapter sleeves are used on smooth shafts, the bearing can be located at any position on the shaft.

4) When used on stepped shafts, together with an abutment ring, bearings can be accurately positioned axially and bearing dismounting is also facilitated.

7.Payment: T/T or L/C
