Withdrawal Sleeve AH318 AH319 AH320 AH322 AH324 AH326 AH328 AH330 AH332 AH334

Price:	1.0~5.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Tianjin, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: AH319 AH320 AH322

Production Capacity: 1000000 sets / week

Delivery Date: according to the quantity

Means of Transport: Ocean,Air

Packing: as per customer's requireme...

reasonable price and good quality

1.Product name: Withdrawal Sleeve

AH318 AH319 AH320 AH322 AH324 AH326 AH328 AH330 AH332 AH334

2.Type of Withdrawal Sleeve: AH300 Series

3. Specification of Withdrawal Sleeve:

Item No	Dimensions(mm)
Item No	d₁	d	B₃	B₄	D₁	D₂	a	b	f	G
AH318	85	90	53	57	93.75	93	12	9	3	M100x2
AH319	90	95	57	61	99.00	98.5	13	10	4	M105x2
AH320	95	100	59	63	104.17	103.5	13	10	4	M110x2
AH322	105	110	63	67	114.33	113.5	15	12	4	M120x2
AH324	115	120	69	73	124.75	124	16	13	4	M130x2
AH326	125	130	74	78	135.08	134.5	17	14	4	M140x2
AH328	135	140	77	82	145.42	144.5	17	14	4	M150x2
AH330	145	150	83	88	155.83	155	18	15	4	M165x3
AH332	150	160	88	93	166.17	165	19	16	5	M180x3
AH334	160	170	93	98	176.50	175	20	17	5	M190x3

4.Package of Withdrawal Sleeve: according to the customer's requirements, general the packages is box.

5.Usage of Withdrawal Sleeve: Adapter Sleeves are used to secure having a tapered bore on cylindrical shaft seatings. That facilitate bearing mounting and dismounting and often simplify Bearing arrangement design.

6.Features of Withdrawal Sleeve: great precision and excellent performance

7.Payment of Withdrawal Sleeve: T/T or L/C

8.Delivery date of Withdrawal Sleeve: according to the quantity
